Page 1 MZ - X500 MZ - X300 USER’S GUIDE ( Tutorial ) Before using this Digital Keyboard for the first time, be sure to read the separate USER’S GUIDE (Basics) to familiarize yourself with basic operations. Page 2: Table Of Contents Contents General Guide EN-2 Editing Events EN-62 Displaying the EVENT EDIT Screen.EN-62 Editing a Tone (User Tones) EN-5. Innovative products bring joy, create new lifestyle and pave the way for related economies - especially, if they have been developed by CASIO. Experience how creativity becomes contribution.
Casio Mz X500 Tutorial
| Keyboard | |
|---|---|
| Touch Response | 3 sensitivity levels, Off |
| Sound Source | |
| Polyphony (max) | 128 |
| Number of Built-in Tones | |
| Stereo Sampled Piano Tones | Yes |
| Tone Edit | |
| User Tone | 650 |
| Drawbar Organ Function | 9 drawbars (16', 5 1/3', 8', 4', 2 2/3', 2', 1 3/5', 1 1/3', 1') |
| Virtual Tone Wheel | |
| Preset Virtual Tone Wheel Organ Tones | 75 (Included in 1,100 preset tones.) |
| User Virtual Tone Wheel Organ Tones | |
| Percussion | Second / Third |
| On Click | |
| Off Click | On / Off |
| Rotary Effect | |
| Reverb | 20 |
| Chorus | |
| Delay | 20 |
| DSP | Equalizer, Compressor, Limiter, Enhancer, Early Reflection, Phaser, Chorus, Flanger, Tremolo, Auto Pan, Rotary, Drive Rotary, LFO Wah, Auto Wah, Distortion, Pitch Shifter, Multi Chorus, Ring Modulator, Delay, Piano Effect |
| Master Comp | |
| Master EQ | 4 Bands Parametric EQ |
| Auto Harmonize | |
| Arpeggiator | 100 types |
| User Arpeggio | |
| Layer | Lower 1 - 4, Upper 1 - 4 Assignable (Max 4 Tones) |
| Split | |
| Number of Built-in Rhythms | 330 |
| One Touch Preset | |
| Auto Accompaniment | CASIO chord, Fingered 1, Fingered 2 (6th off), Fingered 3 (on bass), Full Range Chord |
| Controllers | Start/Stop, Intro1 - 2, Variation1 - 4/Fill-in, Break, Fade In/Out, Ending1 - 2, Synchro Start, Synchro Stop, Accomp On/Off, Ritardando, Auto Fill-In, Tap Start |
| Chord Type | |
| Pattern Sequencer | Real-time Recording, Event Edit (Delete, Copy, Insert, Quantize, Step Recording ), Part Parameters, SMF Import |
| User Rhythms | |
| Number of Demonstration Songs | 6 |
| Number of Music Preset | |
| User Presets | 100 |
| MIDI Recorder | Real-time Recording, Track Edit, Event Edit ( Delete, Copy, Insert, Quantize, Step Recording ), Punch-In/Out, Over Dubbing, SMF Import |
| User Songs | 100 songs, 17 tracks per song (1 system track + 16 multi tracks) |
| Approximate Data Capacity | |
| Recording Source | Keyboard play, keyboard play with Auto Accompaniment and with Music Preset, MIDI Recorder playback, sound input from EXT IN (LINE IN, MIC IN) |
| Audio File Format | |
| Recording Capacity | Up to 100 audio files (maximum recording time: approximately 90 minutes for a single audio file) |
| Center Cancel | |
| Requirement | USB memory, up to 32GB |
| Number of Pads | |
| Velocity | Yes |
| Phrase | |
| Sampling | 30 |
| Chord | |
| Multi | 20 |
| User | |
| LED | Yes |
| Sampling Time | |
| Event Edit | Yes |
| Chord Sync | |
| Synchro | Yes |
| Articulation | |
| Mixer | 48 channels + EXT IN (LINE IN, MIC IN), 9-slider operation |
| Registration | |
| Freeze | Yes |
| Registration Sequence | |
| Pedal SW Assignable | Yes |
| Sustain On / Off SW | |
| Scale Tuning | Equal temperaments plus 16 other types, Scale Fine Tune ±99 cents |
| Key Transpose | |
| Tuning Control | 415.5 - 440.0 - 465.9Hz (0.1Hz units) |
| Octave Shift | |
| Metronome | 0(Off), 1 - 9 beats |
| Tempo Range | |
| Volume | Adjustable |
| Display | |
| Pitch Bend Wheel | Pitch bend range: 0 to 24 semitones |
| Modulation Wheel | |
| Knobs | 3 (Assignable x 2, Value x 1) |
| Sliders | |
| General MIDI | 16 channel multi-timbre received, GM Level 1 standard |
| Internal User Memory (Tone, Rhythm, Song, Registration, etc) | |
| PEDAL 1 | Yes (Mono standard jack) |
| PEDAL 2 / EXPRESSION | |
| PHONES | Yes (Stereo standard jack, Front) |
| LINE OUT | |
| LINE IN | Yes (L/MONO, R for each; Standard jack) |
| MIC IN | |
| USB TO HOST | Yes |
| USB TO DEVICE | |
| MIDI IN, OUT/THRU | Yes |
| DC IN | |
| Supported USB Memory | up to 32GB |
| Functions | SMF Playback (up to 320KB per file), File Storage, File Recall, File Delete, Format, Audio Data Playback / Storage |
| Save/Load | User Tone, User Rhythm, User MIDI Data, User Music Preset, User Registration Memory, User Pad Bank, User Sample, User Phrase, User Arpeggio |
| Size | |
| Bass-reflex System | Yes |
| Speaker ON/OFF | |
| Amplifiers | 20W + 20W |
| W x D x H | |
| Weight | 16.8 lbs. |
| AC Adaptor | |
| Included Accessories | AC adaptor, music stand |
| Stand | |
| Pedal | SP-20, SP-3 |
| UPC Code |
