T Slot Aluminum Profile
- Framing profiles for T-slot structural framing systems are straight sections of extruded aluminum used to create custom building projects. These bars have recessed T-slots that accept hardware for creating joints or mounting components like hinges, connectors, and support plates.
- Parker modular t-slot aluminum profile system, also known as IPS, has conquered the world of machine building, industrial automation, material handling, machine safety guarding,.
- See all of MiniTec's Structural T-Slotted Profiles. MiniTec's Universal T-Slot. MiniTec has a full machine shop & offers profile machining as well as machining of custom plates & sheet metal up to 7' x 12' Unique Tear Away T-Slot. Easy Fastening Of Bolt On Panels. MiniTec supplies bent sheet metal.
T-Slot / V-Slot
T-Slot has been around for many years. It has matured to a solid building system using in industry and by hobby engineers to build everything from machine enclosures to CNC machines, 3D printers and robots! It is strong enough to withstand many industrial stresses and modular enough allow for universal designs.
The T-slot system consists of extruded aluminum of various sizes with a “T” shaped slot on one or more of its sides. The shapes, sizes and designs may be different, but the “T” slot is common to all. The “T” slot allows of a variety of hardware to be connected to the extrusion so that complex structures can be constructed.
In a nutshell, T-slot aluminum forms the basis of a framing system for creating three-dimensional structural assemblies made with a variety of extruded and fabricated aluminum parts.
Types of T-Slot
There are many types of T-Slot available on the market. Some of the most common for small scale engineering include:
- V-Slot
- MakerBeam
- OpenBeam
- MicoRax
As show above, these 4 type range from 10mm to 20mm square profile. Each profile has its unique features, but all share the “T” slot function.
The profiles are not limited to square. V-slot, for example, comes in 4 sizes 20x80mm, 20x60mm, 20x40mm and 20x20mm :
Some manufactures produce larger square and other shaped profiles:
T Slot Aluminum Profiles 8020
MakerBeam can fit a screw into its T-slot:
MicroRax is small, light and uses t-nuts and screws:
OpenBeam can fit a standard nut into its t-slot:
V-Slot uses t-nuts and is different from the other profiles because has “V” grooves that fit special “V” wheels and allow for easy linear motion:
T-slot Aluminum Profiles Dimensions Fusion 360
Above are four different approaches to T-slot, there are in fact many more.
